Shenzhen Connector Technology Co., Ltd
DB9 Welding Wire Waterproof Male Mead
DB9 Welding Wire Waterproof Male Mead
DB9 Welding Wire Waterproof Male Mead
Details



Technical Specifications

● Rated current: 5A

● Dielectric withstand voltage: 1000V AC for 1 minute

● Contact resistance: ≤15mΩ

● Insulation resistance: ≥5000MΩ

● Temperature Range: -25℃ to +85℃

● Protection Class: IP68

● Contact material: Copper alloy, contact area plated with G/F

● Enclosure material: Steel, nickel-plated

● Core material: PBT + 30% GF

● Post-sealing material: PBT+30GF%
