Technical Specifications
● High frequency contact characteristic impedance: 50 Ω, 75 Ω
● Rated current with signal contact: 5.0A
● Working voltage: 250V
● Dielectric withstand voltage: 750V AC for 1 minute
● High frequency contact resistance: 15m Ω
● Insulation resistance: 2000M Ω Min at 500V DC
● Temperature range: -55 ℃ to+105 ℃
● Protection level: IP20
● Shell material: steel or copper alloy, surface treated with tin plating or nickel
● Insulator material: PBT+30% GF (fire rating UL94V-0)
● High frequency contact material: copper alloy, gold-plated
● Signal contact material: copper alloy, gold-plated
● Bracket/screw material: copper alloy, nickel plating
