Technical Specifications
● Rated current: 10A、20A、30A、40A
● Dielectric withstand voltage: 1000V AC for 1 Minute
● Contact resistance: ≤ 2.7m Ω
● Insulation resistance: ≥ 5000M Ω
● Temperature range: -25 ℃ to+85 ℃
● Protection level: IP20
● ROHS compliant
● Contact material: Copper alloy, nickel plated with precious metals
● Front shell material: steel, nickel plated
● Rear shell material: steel, tin plated
● Screw material: copper alloy, nickel plating
● Insulator material: PBT+30% GF
● Rivet insert material: copper alloy, nickel plating
