Technical Specifications
● Rated current: 5A
● Dielectric withstand voltage: 1000V AC
● Contact resistance: ≤ 35m Ω
● Insulation resistance: ≥ 5000M Ω
● Temperature range: -25 ℃ to+85 ℃
● Protection level: IP20
● Contact material: Copper alloy, nickel plated with precious metals
● Front shell material: Steel, nickel plated
● Rear shell material: Steel, tin plated
● Insulator material: PBT+30% GF (black, white, blue)
