The SZCNT58-QC1 series has a metal shell with good shielding effect, which can achieve 360 degree shielding. It has a small volume and is particularly suitable for situations with limited space. Its connection method adopts a push-pull connection and a secondary locking method, making it easy to operate and reliable to connect. The product has the characteristics of fast connection, high-level sealing, and good salt spray resistance.
Technical Indicators
| Working temperature | -40 ～ +125℃ |
| Relative humidity | 90% ～ 95%(40±2℃ ) |
| Working pressure | 4.39KPa~101.33KPa |
| Salt spray performance | 48-120h |
| Waterproof rating | IP67 |
| Working voltage | 1000V |
| Vibration | 10-2000Hz, 196m/s2 instantaneous break ≤ 1 μ s |
| Impact | 980m/s2 instantaneous break ≤ 1 μ s |
| Mechanical lifespan | 500 times |
| Insulation resistance | ≥ 5000M Ω |
| Withstand voltage | 1500-3000V |
Working Current and Contact Resistance
| Contact fitting diameter (mm) | Contact resistance (m Ω) | Working current (A), temperature rise less than 45 degrees | Cable diameter (mm ²) |
| 6 | ≤ 0.3 | 120A | 25,35
|
| 12 | ≤ 0.1 | 250A | 50,70 |
